Description
Device Management
Camera
Up to 8 cameras
Device Compatibility
All Reolink Wi-Fi/PoE cameras (Battery cameras require a firmware upgrade)
Safety Protection
Account access and sharing options for individual devices are only available through Home Hub
Input/Output
HDMI
NO
USB
NO
Reset Button
YES
Power
DC 12V/1A
Speaker
YES (Max. 115dB)
Ethernet
1*10M/100M bit RJ45 port for WAN
Storage
SATA
NO
microSD Card Slot
Up to 512GB*2
Backup Media
NO
Storage Encryption
Protect privacy and prevent theft with AES-128 encryption algorithm
Preview & Playback
Live View
APP, PC Client
Playback
Smart playback/event history
Wi-Fi
Wireless Standard
IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
Operating Frequency
2.4/5 GHz
Wireless Security
WPA/WPA2/WPA3
Sub-1 GHz
Operating Frequency
868/915MHz
System
Network Protocols
TCP/IP, UDP, DHCP, P2P, UPNP, RTSP,RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Max. User Access
11 users (1 admin account & 10 shared accounts)
Smart Home
Google Assistant
Working Environment
Operating Temperature
-10℃~+45℃
Operating Humidity
10%~90%
Mechanical
Dimensions
95*95*161.8mm
Weight
441g
