Description
Video & Audio
Image Sensor
1/2.7″ CMOS sensor
Resolution
7680×2160 (16MP) @ 20FPS
Lens
f=2.8mm/F1.6
Video Compression
H.265
Field of View
Horizontal: 180° Vertical: 55°
Infrared Night Vision
30 meters (LED: 6pcs/20mil/850nm) (Auto-switching with IR-cut filter)
Color Night Vision
With spotlight: 8pcs/5W/6500K/560 Lumens
Frame Rate
Main stream: 4fps – 20fps (default: 20fps) Sub stream: 4fps – 20fps (default: 20fps)
Code Rate
Mainstream: 3072-10240Kbps (default: 8192kbps) Substream: 256-2045Kbps (default: 1024kbps)
Audio
Two-way audio
DC Power
DC 12.0V⎓2A, <12W
Power Requirements
PoE
IEEE 802.3af, 48V, active
Interface
Power Port
DC power port
Ethernet Port
One 10M/100Mbps; RJ45
SD Card Slot
Supports Max. 256GB microSD card
Reset Button
YES
Audio In/Out
Built-in microphone and speaker
Software
Browsers Supported
Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Protocols & Standards
HTTPS, SSL, TCP/IP, UDP, HTTP,IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
User Access
Max. 20 users (1 admin & 19 user); Max. 12 simultaneous streams (2 main & 10 sub streams)
Other Features
Smart Alarm
Motion detection; person detection; vehicle detection; animal detection
Recording Modes
Motion-triggered recording (default); scheduled recording, 24/7 recording
Time Lapse
YES
Smart Home Compatibility
Google Assistant
Working Environment
Operating Temperature
-10°C~+55°C (14°F~13
Operating Humidity
10% ~ 90%
Weatherproof
IP67
Mechanical
Dimensions
195x103x56 mm
Weight Battery Included
680g
